Mercedes-Benz C-class W202 (1993-1997) Air conditioning circuits

1995 VFTC A/C COMPRESSOR A/C PUSHBUTTON CONTROL UNIT (CENTER OF I/P) A/C SYSTEM BLOWER UNIT AUXILIARY COOLANT PUMP AUXILIARY FAN AUXILIARY FAN PRERESISTOR AUXILIARY FAN RELAY MODULE (STAGE 1) (LEFT REAR OF ENGINE COMPT) AUXILIARY FAN RELAY MODULE (STAGE 2) (LEFT REAR OF ENGINE COMPT) BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL/RED WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/PNK WIRE BLU/RED WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CRUISE CONTROL/ IDLE SPEED CONTROL MODULE (IN RIGHT COMPONENT COMPT) DATA LINK CONNECTOR (LEFT REAR OF ENGINE COMPT) DUOVALVE ECT SENSOR (A/C) ENGINE CONTROL MODULE (IN RIGHT COMPONENT COMPT) FUSE 13 FUSE 3 FUSE 5 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/PNK WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/PNK WIRE GRY/RED WIRE GRY/YEL WIRE HEATER CORE TEMPERATURE SENSOR HOT AT ALL TIMES HOT IN RUN FUSE BOX FUSE 3 HOT IN RUN OR START IN-CAR TEMPERATURE SENSOR INSTRUMENT CLUSTER MAXI FUSE BOX FUSE 14 NCA WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RED/YEL/WHT WIRE REFRIGERANT PRESSURE SENSOR SWITCHOVER VALVE BLOCK W/ TRACTION CONTROL W/O TRACTION CONTROL WHT/BLU WIRE WHT/BRN WIRE WHT/PNK WIRE WHT/VIO WIRE
