Emergency seat belt tensioners circuit for Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011)
Emergency seat belt tensioners circuit
30 31 CAN L CAN H
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK/CARGO AREA)
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
