Electronic suspension circuit for Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011)

30 H SIDE ADAPTIVE DAMPING SYSTEM CONTROL UNIT BLK/BLU WIRE BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE FUSE GND GND GRN/WHT WIRE HOT AT ALL TIMES INTERIOR FUSE BOX (BEHIND LEFT END OF DASH) L SIDE L SIDE SIG LEFT FRONT LEVEL SENSOR (IN LEFT FRONT WHEELWELL) LEFT REAR AXLE DAMPING VALVE UNIT LEFT REAR BODY LATERAL ACCELERATION SENSOR LEFT REAR LEVEL SENSOR (IN LEFT REAR WHEELWELL) NCA WIRE PNK/RED WIRE RED/BLU WIRE RIGHT REAR AXLE DAMPING VALVE UNIT RIGHT REAR LEVEL SENSOR SIG SIG 31 H SIDE WHT/BLU WIRE WHT/RED WIRE YEL/WHT WIRE

ADAPTIVE DAMPING SYSTEM CONTROL UNIT BLK/BLU WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/YEL WIRE CAN E H CAN E L COMPUTER DATA LINES SYSTEM GND SIG GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/WHT WIRE H SIDE H SIDE GND L SIDE LEFT FRONT AXLE DAMPING VALVE UNIT LEFT FRONT BODY LATERAL ACCELERATION SENSOR NCA WIRE PNK/WHT WIRE RIGHT FRONT AXLE DAMPING VALVE UNIT RIGHT FRONT BODY LATERAL ACCELERATION SENSOR RIGHT FRONT LEVEL SENSOR SIG SIG GND VIO/BLU WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BLU WIRE YEL/WHT WIRE
