Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011) xenon bulb w/ integrated ignition module Wiring diagram

1 2 3 30 31 LIN 1 12 13 17 18 CAN E L CAN E H CAN B L CAN B H 2 1 CAN-E H CAN-E L 2 11 1 31 SIG 2 3 CAN-G H CAN-G L BRN WIRE BRN/RED WIRE COMBINATION SWITCH COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SWITCH FOG LAMP INDICATOR LAMP FRONT ELECTRICAL PREFUSE BOX (AT RIGHT REAR OF ENGINE COMPT) FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT) FUSE 105 FUSE 89 GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY/YEL WIRE HEADLAMP FLASHER/ HIGH BEAM SWITCH HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR HIGH BEAM HIGH BEAM INDICATOR HIGH BEAM LAMP HIGH BEAM SOLENOID HOT AT ALL TIMES HOT AT ALL TIMES 9 10 CAN-B H CAN-B L FUSE 18 HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT PANEL SWITCH GROUP LEFT FOG LAMP LEFT FRONT HEADLAMP UNIT LEFT FRONT LEVEL SENSOR (IN LEFT FRONT WHELLWELL) LEFT REAR LEVEL SENSOR (IN LEFT REAR WHELLWELL) LEFT XENON LAMP CONTROL UNIT LIN 1 LOW BEAM SWITCH REAR FOG LAMP INDICATOR LAMP RED WIRE RED/GRY WIRE RIGHT FOG LAMP RIGHT FRONT HEADLAMP UNIT RIGHT XENON LAMP CONTROL UNIT SIG CAN-G L CAN-G H STANDING LAMPS INDICATOR LAMP STEERING COLUMN MODULE CONTROL UNIT (TOP OF STEERING COLUMN) SWITCH ILLUMINATION WHT WIRE WHT/BLK WIRE WHT/RED WIRE XENON BULB W/ INTEGRATED IGNITION MODULE YEL WIRE YEL/WHT WIRE
