Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011) left sun left front visor mirror lamp mirror lamp switch Wiring diagram
This page shows the only wiring diagram for the component.left sun left front visor mirror lamp mirror lamp switch, which is found in the car Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left sun left front visor mirror lamp mirror lamp switch (1 of 1)
10 9 CAN B L CAN B H
30 31 11 12 SIG SIG (+) (+)
31 30 CAN B L CAN B H
6 3 2 PNK WIRE
6 7 CAN B L CAN B H
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FL 31 31
FRONT DOME LAMP SWITCH
FRONT SAM CONTROL UNIT
FUSE 21 W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT)
GLOVE BOX LAMP)
GLOVE BOX LAMP/ SWITCH
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/WHT WIRE
INTERIOR LAMP AUTOMATIC FUNCTION SWITCH
INTERIOR PROTECTION SWITCH
LEFT FRONT INTERIOR LAMP
LEFT FRONT READING LAMP SWITCH
LEFT REAR READING LAMP
LEFT SUN LEFT FRONT VISOR MIRROR LAMP MIRROR LAMP SWITCH
PNK WIRE
PNK/YEL WIRE
REAR DOME LAMP
REAR DOME LAMP, SWITCH
REAR INTERIOR LAMP
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK/CARGO AREA)
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT FRONT INTERIOR LAMP
RIGHT FRONT MIRROR LAMP SWITCH
RIGHT FRONT READING LAMP SWITCH
RIGHT REAR READING LAMP
RIGHT SUN VISOR MIRROR LAMP
W/ AVANTGARDE, ELEGANCE
W/ CLASSIC
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> LEFT SUN LEFT FRONT VISOR MIRROR LAMP MIRROR LAMP SWITCH
