Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011) left computer data lines system rear lamp backup unit lamp Wiring diagram
This page shows the only wiring diagram for the component.left computer data lines system rear lamp backup unit lamp, which is found in the car Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left computer data lines system rear lamp backup unit lamp (1 of 1)
10 9 CAN B L CAN B H
21 22 RFL-R RFL-L
6 7 CAN C L CAN C H
BACKUP CAMERA VOLTAGE SUPPLY MODULE
BACKUP LAMP
BACKUP LAMP SWITCH (M/T) (ON RIGHT REAR OF TRANSMISSION)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B L CAN B H
COMPUTER DATA LINES SYSTEM
ELECTRONIC SELECTOR LEVER MODULE CONTROL MODULE (A/T) (UNDER CENTER CONSOLE)
FRONT
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT)
FUSE 106 ELECTRICAL PREFUSE BOX (AT RIGHT REAR OF ENGINE COMPT)
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
LEFT COMPUTER DATA LINES SYSTEM REAR LAMP BACKUP UNIT LAMP
MODEL CODE 204.0 MODEL CODE 204.2
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK/CARGO AREA)
RED WIRE
RFL (+)
RIGHT REAR LAMP UNIT
WHT WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> LEFT COMPUTER DATA LINES SYSTEM REAR LAMP BACKUP UNIT LAMP
