Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011) from fuse 67 (diagram Wiring diagram
This page shows the only wiring diagram for the component.from fuse 67 (diagram, which is found in the car Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram from fuse 67 (diagram (1 of 1)
BRN WIRE
CARGO AREA SOCKET
FROM FUSE 60 (DIAGRAM 2 OF 5) FROM FUSE 84 (DIAGRAM 2 OF 5)
FROM FUSE 67 (DIAGRAM
FROM FUSE 74 (DIAGRAM
FROM VEHICLE INTERIOR POWER OUTLET (DAIGRAM 2 OF 5)
FUSE
FUSE 51
FUSE 67 FUSE 68 RES
FUSE 70
FUSE 72
FUSE FUSE
FUSE FUSE FUSE 69
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR (IF EQUIPPED)
PNK/BLK WIRE
PNK/GRN WIRE
REAR BASS SPEAKER AMPLIFIER (W/ SOUND SYSTEM)
REAR WINDOW DEFROSTER RELAY
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY(2)
RES RES FUSE FUSE FUSE FUSE
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR (IF EQUIPPED)
SOUND SYSTEM AMPLIFIER CONTROL UNIT (IF EQUIPPED)
TIRE PRESSURE MONITOR CONTROL UNIT (IF EQUIPPED)
TO FUSE 70 (DIAGRAM 3 OF 5)
TO FUSE 75 (DIAGRAM 3 OF 5)
TV TUNER CONTROL UNIT (IF EQUIPPED)
Go to component -> Power distribution circuit (3 of 5) -> FROM FUSE 67 (DIAGRAM
