Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011) electronic selector lever module control module (under center Wiring diagram
This page shows the only wiring diagram for the component.electronic selector lever module control module (under center, which is found in the car Mercedes-Benz C-class AMG W204/S204/С204 (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic selector lever module control module (under center (1 of 1)
31 30 7 34 8 CAN B L CAN B H TG R
40 41 CAN C L CAN C H
41 54 CAN E H CAN E L
6 7 CAN C L CAN C H
7 6 24 5 GSS, BF RETURN LINE SBE GSS, FA
74 75 CAN-E L CAN-E H
ACOUSTIC TURN SIGNAL LIGHT FUNCTION CHECK
ANTI-LOCK BRAKE SYSTEM INDICATOR LAMP
AREA)
BBV HL
BBV HR
BFS
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRAKE FLUID, PARKING BRAKE WARNING LAMP (EXCEPT USA)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B L CAN B H
CAN E H
CAN E L
CAN-E L CAN-E H
COMPUTER DATA LINES SYSTEM
CONSOLE)
COOLANT TEMPERATURE GAUGE
DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH (IN DRIVER'S SEAT BELT BUCKLE)
ELECTRONIC SELECTOR LEVER MODULE CONTROL MODULE (UNDER CENTER
ELECTRONIC STABILITY PROGRAM WARNING LAMP
ELECTRONIC TRANSMISSION CONTROL UNIT
ENGINE COOLANT TEMPERATURE MALFUNCTION INDICATOR
ENGINE DIAGNOSIS MALFUNCTION INDICATOR LAMP
FRONT PASSENGER SEAT OCCUPIED RECOGNITION (W/ SEAT BELT REMINDER WARNING)
FUEL LEVEL INDICATOR
FUEL RESERVE INDICATOR LAMP
FUSE 28
GEAR DISPLAY (PRND)
GRN WIRE
GRN/WHT WIRE
GRY/GRN WIRE
HIGH BEAM INDICATOR LAMP
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION
INSTRUMENT ILLUMINATION BRIGHTNESS CONTROL
LEFT FUEL LEVEL INDICATOR SENSOR (IN FUEL TANK)
LEFT TURN SIGNAL IND LAMP
ME-SFI (ME) CONTROL MODULE (TOP CENTER OF ENGINE)
MULTI-FUNCTION DISPLAY
NCA WIRE
PARKING BRAKE INDICATOR SWITCH (ON PARKING BRAKE SUPPORT BRACKET)
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK/CARGO
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT BRAKE WEAR SENSOR (AT RIGHT FRONT BRAKE ASSEMBLY)
RIGHT FUEL LEVEL INDICATOR SENSOR (IN FUEL TANK)
RIGHT REAR BRAKE PAD WEAR SENSOR (AT RIGHT REAR BRAKE ASSEMBLY)
RIGHT TURN SIGNAL IND LAMP
SEAT BELT REMINDER LAMP
SERVICE BRAKE INDICATOR LAMP (USA)
SIG
SPEEDOMETER
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT (UNDER FRONT OF CENTER CONSOLE)
SUPPLEMENTAL RESTRAINT SYSTEM INDICATOR LAMP
TACHOMETER, BRIGHTNESS SENSOR
TG L
TIRE PRESSURE MONITOR WARNING LAMP (IF EQUIPPED)
TRANSMISSION MODE DISPLAY
VIO/GRN WIRE
WARNING BUZZER
YEL WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit -> ELECTRONIC SELECTOR LEVER MODULE CONTROL MODULE (UNDER CENTER
