Trunk, tailgate, fuel door circuit for Mercedes-Benz C-class AMG W203/S203/CL203 facelift (2004-2007)

1 2 CAN B L CAN B H 2 19 15 22 18 TRUNK EMERG TRUNK EMERG TRUNK EXT TRUNK MOTOR TRUNK AJAR 4 5 CAN L CAN H BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FRONT PRE-FUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE 2 FUSE 4 GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES NCA WIRE PNK/RED WIRE REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED WIRE TRUNK LID CENTRAL LOCKING MOTOR TRUNK LID CONTACT SWITCH TRUNK LID EMERGENCY RELEASE SWITCH TRUNK LID EXTERNAL SWITCH VIO/BLU WIRE YEL WIRE
