Power top/sunroof circuit for Mercedes-Benz C-class AMG W203/S203/CL203 facelift (2004-2007)

1 2 3 4 5 6 9 10 11 SHD (+) SHD (-) 1 2 CAN B L CAN B H 31 UKB UKB UKB 9 10 CAN-B L CAN-B H BRN WIRE BRN/GRY WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FRONT PRE-FUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE 2 HALL SENSOR 1 HALL SENSOR 2 HOT AT ALL TIMES NCA WIRE OBSTRUCTION SENSOR OVERHEAD CONTROL PANEL CONTROL MODULE POWER ROOF SWITCH REAR ROLLER BLIND (IF EQUIPPED) REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED WIRE RED/BLU WIRE ROOF DRIVE SYSTEM ROOF MOTOR
