Mercedes-Benz C-class AMG W203/S203/CL203 facelift (2004-2007) passenger seat belt buckle restraint systems switch Wiring diagram

BELT BELT TENSION SENSOR (RIGHT FRONT DOOR SILL) BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/PNK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN L CAN-L CAN-H COMPUTER DATA LINES SYSTEM CRASH SIG 31 31 DRIVER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH DRVR BELT UPFRONT R ETR LF- ETR LF+ ETR RF+ ETR RF- ETR LR- ETR LR+ ETR RR+ ETR RR- PASS BELT FRONT SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE LEFT AIRBAGS SENSOR (UNDER LEFT REAR SEAT) LEFT FRONTAL ACCEL- ERATION SENSOR LEFT REAR ETR SQUIB (UNDER LEFT REAR SEAT) PASSENGER SEAT BELT BUCKLE RESTRAINT SYSTEMS SWITCH PNK WIRE PNK/BLK WIRE PRESS. PRESSURE SENSOR (UNDER RIGHT FRONT SEAT) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RESTRAINT SYSTEMS CONTROL MODULE (UNDER CENTER CONSOLE, LEFT OF SHIFTER) RIGHT AIRBAGS SENSOR (UNDER RIGHT REAR SEAT) RIGHT FRONTAL ACCEL- ERATION SENSOR RIGHT REAR ETR SQUIB (UNDER RIGHT REAR SEAT) SB LF- SB LF+ SB RF+ SB RF- SB LR- SB LR+ SB RR+ SB RR- WB L- WB L+ WB R+ WB R- SIDE L SIDE R UPFRONT L VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/YEL WIRE WEIGHT SENSING SYSTEM (WSS) CONTROL UNIT (UNDER RIGHT FRONT SEAT) WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE
