Mercedes-Benz C-class AMG W203/S203/CL203 (2001-2004) steering column adjustment lock indicator switch Wiring diagrams

1 2 3 6 7 8 ESA SW ESA SW ESA SW ESA SW ESA SW ESA SW 2 1 CAN-B H CAN-B L 2 MEMORY LOCATION 5 6 7 30 CAN-B H CAN-B L 6 5 8 7 2 CAN-C H CAN-C L CAN-B H CAN-B L 31 BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE CAN B L CAN B H CL MODELS COMPUTER DATA LINES SYSTEM DI CONTROL MODULE DRIVER FRONT SEAT ADJUSTMENT CONTROL MODULE (UNDER SEAT) EXCEPT CL MODELS FRONT PRE-FUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE 2 FUSE 21 FUSE 27 FUSE 29 FUSE 31 GRN WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES INTERIOR FUSE BOX (UNDER LEFT END OF DASH) LEFT FRONT DOOR CONTROL MODULE LEFT FRONT DOOR ESA SWITCH GROUP MEMORY STORE NCA WIRE REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SCL STEERING COLUMN ADJUSTMENT LOCK INDICATOR SWITCH STEERING COLUMN HEIGHT ADJUSTMENT MOTOR (UP/DOWN) STEERING COLUMN LOCATION (RAISE/LOWER) (FORWARD/BACK) STEERING COLUMN LONGITUDINAL ADJUSTMENT MOTOR (FWD/BACK) VCS SWITCH VIO WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE

1 2 3 6 7 8 ESA SW ESA SW ESA SW ESA SW ESA SW ESA SW 13 12 10 11 CAN-B H CAN-B L CAN-C H CAN-C L 30 31 2 1 CAN-B H CAN-B L 2 MEMORY LOCATION 4 5 CAN-B L CAN-B H 5 6 7 30 CAN-B H CAN-B L BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE CAN B L CAN B H CL MODELS COMPUTER DATA LINES SYSTEM DRIVER FRONT SEAT ADJUSTMENT CONTROL MODULE (UNDER SEAT) EXCEPT CL MODELS FRONT PRE-FUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE 6 FRONT SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT) FUSE 2 FUSE 21 FUSE 27 FUSE 29 FUSE 31 FUSE 4 GRN WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES INTERIOR FUSE BOX (UNDER LEFT END OF DASH) LEFT FRONT DOOR CONTROL MODULE LEFT FRONT DOOR ESA SWITCH GROUP MEMORY STORE NCA WIRE PNK/RED WIRE REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED WIRE RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SCL STEERING COLUMN ADJUSTMENT LOCK INDICATOR SWITCH STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN HEIGHT ADJUSTMENT MOTOR (UP/DOWN) STEERING COLUMN LOCATION (RAISE/LOWER) (FORWARD/BACK) STEERING COLUMN LONGITUDINAL ADJUSTMENT MOTOR (FWD/BACK) STEERING COLUMN MODULE VIO WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
