Mercedes-Benz C-class AMG W203/S203/CL203 (2001-2004) right front door esa switch group Wiring diagram

1 2 3 4 5 6 BR RELEASE BR RELEASE 1 2 3 4 5 6 HH (-) HH (+) 1 2 3 4 5 6 HV (-) HV (+) 1 2 3 4 5 6 LH (-) LH (+) 1 2 3 6 7 8 ESA SW ESA SW ESA SW ESA SW ESA SW ESA SW 1 2 H RELEASE H RELEASE 2 1 CAN-B H CAN-B L 2 3 4 LK (+) HEAD (+) (+) 5 6 MHEAD (-) MLK (-) 6 7 5 CAN-B H CAN-B L 30 BACKREST BLK WIRE BLK/PNK WIRE BLU WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE CAN B L CAN B H CL MODELS COMPUTER DATA LINES SYSTEM EXCEPT CL MODELS FRONT (RAISE/ LOWER) FRONT PRE-FUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE 2 FUSE 22 FUSE 38 FUSE 40 GRN WIRE HEAD RESTRAINT (RAISE/ LOWER) HOT AT ALL TIMES INTERIOR FUSE BOX (UNDER LEFT END OF DASH) MEMORY LOCATION MEMORY STORE MHH (+) MHH (-) MHV (+) MHV (-) MLH (+) MLH (-) NCA WIRE PASSENGER FRONT SEAT ADJUSTMENT CONTROL MODULE (UNDER SEAT) PASSENGER SEAT BACKREST RELEASE MICROSWITCH (CL MODELS) PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR PASSENGER SEAT HEAD RESTRAINT RAISE/LOWER ADJUSTMENT MOTOR PASSENGER SEAT HEIGHT RELEASE MICROSWITCH (CL MODELS) PASSENGER SEAT REAR UP/DOWN ADJUSTMENT MOTOR REAR (RAISE/ LOWER) REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR CONTROL MODULE RIGHT FRONT DOOR ESA SWITCH GROUP SEAT (FORWARD/ BACK) VIO WIRE WHT WIRE
