Mercedes-Benz C-class AMG W203/S203/CL203 (2001-2004) maf ps sig raf sig raf mtr tva mtr Wiring diagram

AIR PUMP ACT SOL ALTITUDE SENSOR (TOP OF ENGINE) AS SIG TWC TVA SIG BLK WIRE BLK/YEL WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CKP- CKP+ CMP CMP TVA CT CT AS - MAF MAF OIL - TVA TVA SIG RAF RAF SIG TVA MTR ENGINE CONTROL MODULE (ME-SFI) (LEFT REAR OF ENGINE COMPT) FUEL INJECTORS GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HOT FILM MAF SENSOR (TOP OF ENGINE) INJ 2 INJ 4 INJ 3 INJ 1 KS - KS SIG MAF PS - MAF PS SIG RAF SIG RAF MTR TVA MTR OIL SENSOR (LOWER LEFT FRONT OF ENGINE) PRESSURE SENSOR (RIGHT FRONT OF ENGINE) RAF MTR RECIRCULATED AIR FLAP ACTUATOR (RIGHT FRONT OF ENGINE) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE THROTTLE VALVE ACTUATOR (FRONT LEFT SIDE OF ENGINE) TWC OIL SIG TWC TEMPERATURE SENSOR VIO WIRE WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE YEL/WHT WIRE
