Mercedes-Benz C-class AMG W203/S203/CL203 (2001-2004) left rear door central locking motor Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door central locking motor, in which he is found in the car Mercedes-Benz C-class AMG W203/S203/CL203 (2001-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door central locking motor (1 of 2)
1 2 1 11 42 41 CAN-B H CAN-B L
1 6 5 8 7 ESA CAN-B H CAN-B L CAN-B H CAN-B L
1.8L 2.6L, 3.2L 2.3L
11 12 CAN-B H CAN-B L
17 18 12 13 CAN-B L CAN-B H CAN-B L CAN-B H
2 3 DOOR MOTOR DOOR MOTOR
3 4 CAN-B L CAN-B H
6 7 5 4 CAN-B H CAN-B L 30 31
8 6 7 3 2 IR REC IR REC IR REC DOOR MOTOR DOOR MOTOR
BLK WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DI CONTROL MODULE (PROVIDES DRIVE-AWAY PROTECTION)
DISPLAY
ELECTRONIC STEERING LOCK MODULE (ON STEERING COLUMN)
ESA
FUSE 21
FUSE 22
FUSE 33
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTERIOR CENTRAL LOCKING SWITCH
INTERIOR FUSE BOX (UNDER LEFT END OF DASH) FUSE 32
LEFT FRONT DOOR CENTRAL LOCKING MOTOR
LEFT FRONT DOOR CONTROL MODULE
LEFT FRONT IR RECEIVER
LEFT REAR DOOR CENTRAL LOCKING MOTOR
LEFT REAR DOOR CONTROL MODULE (SEDAN, WAGON)
ME-SFI CONTROL MODULE (PROVIDES DRIVE-AWAY PROTECTION)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CENTRAL LOCKING MOTOR
RIGHT FRONT DOOR CONTROL MODULE
RIGHT FRONT IR RECEIVER
RIGHT REAR DOOR CENTRAL LOCKING MOTOR
RIGHT REAR DOOR CONTROL MODULE (SEAN, WAGON)
UPPER CONTROL PANEL CONTROL MODULE
WHT WIRE
WHT/RED WIRE
Go to component -> Anti-theft circuit (2 of 2) -> LEFT REAR DOOR CENTRAL LOCKING MOTOR
Wiring diagram left rear door central locking motor (2 of 2)
11 12 CAN-B H CAN-B L
11 15 CAN-B H CAN-B L
2 3 DOOR MOTOR DOOR MOTOR
33 34 36 37 42 43 45 46 SS RF SS RF SS LR SS LR SS RR SS RR SS LF SS LF
6 7 5 4 CAN-B H CAN-B L 30 31
8 6 7 3 2 IR REC IR REC IR REC DOOR MOTOR DOOR MOTOR
BLK WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
ESP, BAS CONTROL MODULE
FUSE 21
FUSE 22
FUSE 33
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
INTERIOR FUSE BOX (UNDER LEFT END OF DASH) FUSE 32
LEFT FRONT DOOR CENTRAL LOCKING MOTOR
LEFT FRONT DOOR CONTROL MODULE
LEFT FRONT IR RECEIVER
LEFT REAR DOOR CENTRAL LOCKING MOTOR
LEFT REAR DOOR CONTROL MODULE (SEDAN, WAGON)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR CENTRAL LOCKING MOTOR
RIGHT FRONT DOOR CONTROL MODULE
RIGHT FRONT IR RECEIVER
RIGHT REAR DOOR CENTRAL LOCKING MOTOR
RIGHT REAR DOOR CONTROL MODULE (SEDAN, WAGON)
TO WHEEL SPEED SENSORS
WHT WIRE
Go to component -> Power door locks circuit (2 of 2) -> LEFT REAR DOOR CENTRAL LOCKING MOTOR
