Mercedes-Benz C-class AMG W202 facelift (1997-2000) pse control module interior lights system, anti- theft system Wiring diagram
This page shows the only wiring diagram for the component.pse control module interior lights system, anti- theft system, which is found in the car Mercedes-Benz C-class AMG W202 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pse control module interior lights system, anti- theft system (1 of 1)
A/C SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/YEL WIRE
CF RELAY MODULE,
CLK 320
DRIVER'S SIDE DOOR CONTROL MODULE
DRIVER'S SIDE FUSE, RELAY BOX
FP RELAY MODULE PSE CONTROL MODULE
FROM BATTERY (DIAGRAM 1 OF 2)
FROM TERMINAL
FRONT PASSENGER'S SIDE DOOR CONTROL MODULE
FUSE
FUSE 1
FUSE 1 FUSE 2
FUSE 10
FUSE 11 25
FUSE 11 FUSE 12
FUSE 12
FUSE 13
FUSE 2 FUSE 3
FUSE 28
FUSE 29
FUSE 3
FUSE 37
FUSE 4
FUSE 5
FUSE 5 FUSE 4
FUSE 6
FUSE 7
FUSE 7 FUSE 6
FUSE 8
FUSE 9
FUSE FUSE 38 RELAY BOX
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER
INTERIOR LIGHTS SYSTEM, CF RELAY MODULE
LEFT FOOTWELL)
NCA WIRE
PNK/WHT WIRE
POWER TOPS SYSTEM
PSE CONTROL MODULE
PSE CONTROL MODULE INTERIOR LIGHTS SYSTEM, ANTI- THEFT SYSTEM
REAR FUSE BOX
RED WIRE
RED/GRY WIRE
RELAY BOX FUSE 30 10
ROOF CONTROL PANEL CONTROL MODULE
SEATS SYSTEM
TERMINAL
W/ CABRIOLET
W/ IR, ATA
W/ LEFT ESA
W/ RIGHT ESA
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 2) -> PSE CONTROL MODULE INTERIOR LIGHTS SYSTEM, ANTI- THEFT SYSTEM
