Mercedes-Benz C-class AMG W202 facelift (1997-2000) passenger's door control module Wiring diagram
This page shows the only wiring diagram for the component.passenger's door control module, which is found in the car Mercedes-Benz C-class AMG W202 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's door control module (1 of 1)
1 2 3 4 BATTERY
1 8 4 7 9 3 2 SIGNAL BATTERY CAN L
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
CAN H GROUND
CAN L CAN H BATTERY GROUND
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL MODULE
FUSE 17
FUSE 3
FUSE 5
FUSE 7
FUSE 8
FUSE, RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT)
GRN WIRE
GROUND
GRY/BLU WIRE
HOT AT ALL TIMES
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR DOOR CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH
LOWER CONTROL FIELD CONTROL MODULE
PASSENGER'S DOOR CONTROL MODULE
REAR FUSE BOX (RIGHT SIDE OF TRUNK)
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT POWER WINDOW MOTOR
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR POWER WINDOW SWITCH
Go to component -> Power window circuit -> PASSENGER'S DOOR CONTROL MODULE
