Mercedes-Benz C-class AMG W202 facelift (1997-2000) modul- ator valve shift valve lock up valve Wiring diagram

1 2 4 5 9 10 PWR TR OUT A OUT B OUT C OUT D OUT 2-3 SHIFT VALVE 3-4 SHIFT VALVE 1-2/ 4-5 VALVE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/VIO WIRE CAN (-) CAN (+) CLK 320 CLK 430 COMPUTER DATA LINES SYSTEM DATA A DATA B DATA C DATA D POWER GROUND DAYTIME RUNNING LIGHT CONTROL MODULE (BEHIND LEFT SIDE OF DASH) DRIVER'S SIDE FUSE, RELAY MODULE BOX (LEFT REAR OF ENGINE COMPT) ELECTRONIC IGNITION LOCK CONTROL MODULE (ON IGNITION SWITCH) FUSE 3 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES ILLUM ILLUMINATION CONTROL MODULE INTERLOCK SWITCH KICKDOWN SWITCH (TOP OF ACCELERATOR PEDAL) MODUL- ATOR VALVE SHIFT VALVE LOCK UP VALVE PASSENGER'S SIDE FUSE, RELAY MODULE BOX (RIGHT REAR OF ENGINE COMPT) PNK WIRE PNK/RED WIRE POLARITY PROTECTION RELAY R/P LOCK SOLENOID (BEHIND LEFT SIDE OF DASH) RPM SENSOR 2 RPM SENSOR 3 STRTR LOCK-OUT TEMP SENSOR TRANSMISSION CONTROL MODULE (REAR OF ENGINE COMPT) TRANSMISSION RANGE RECOGNITION SWITCH (BASE OF GEAR SELECTOR LEVER) VALVE UNIT (ELECTRONIC TRANSMISSION CONTROL) VIO WIRE WHT WIRE WHT/GRN WIRE YEL WIRE
