Mercedes-Benz C-class AMG W202 facelift (1997-2000) instrument cluster, exterior lights system Wiring diagram
This page shows the only wiring diagram for the component.instrument cluster, exterior lights system, which is found in the car Mercedes-Benz C-class AMG W202 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram instrument cluster, exterior lights system (1 of 1)
A/C
A/C SYSTEM
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CF RELAY MODULE,
CLK 320
COMBINATION SWITCH
CTEL INTERFACE
DRIVER'S SIDE FUSE, RELAY MODULE BOX
ELECTRONIC IGNITION LOCK CONTROL MODULE
ESC CONTROL MODULE
EXTERIOR LAMP SWITCH
EXTERIOR LIGHTS SWITCH
EXTERIOR LIGHTS SYSTEM,
FRONT CIGAR LIGHTER
FUSE 1
FUSE 11 FUSE 10
FUSE 12
FUSE 14
FUSE 16
FUSE 17
FUSE 18
FUSE 2
FUSE 23
FUSE 24 FUSE 25
FUSE 26
FUSE 27 FUSE 22
FUSE 4 FUSE 3
FUSE 5
FUSE 6 7.5 FUSE 15 FUSE 13
FUSE FUSE 19
FUSE/ RELAY BOX
GLOVE COMPARTMENT LAMP, GARAGE DOOR OPENER
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEATED SEATS CIRCUIT
ILLUMINATION CONTROL MODULE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEM
LEFT FOOTWELL)
MIRRORS SYSTEM
NCA WIRE
PASSENGER'S SIDE FUSE/ RELAY MODULE BOX
PNK PNK WIRE
PNK WIRE
PNK/RED WIRE
PNK/YEL WIRE
REAR WINDOW SUNSHADE SWITCH, NAVIGATION PROCESSOR, POWER TOPS SYSTEM
RED WIRE
SEATS SYSTEM
SOUND SYSTEMS, CTEL TRANSMITTER/ RECEIVER
SOUND SYSTEMS, CTEL TRANSMITTER/ RECEIVER SOUND SYSTEMS
STARTER
STEERING ANGLE SENSOR
STEERING LOCK
SUPPLEMENTAL RESTRAINTS SYSTEM
SYSTEM
TERMINAL
TO REAR FUSE BOX (DIAGRAM 2 OF 2)
TO TERMINAL
ULTRASONIC PTS CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 2) -> INSTRUMENT CLUSTER, EXTERIOR LIGHTS SYSTEM
