Mercedes-Benz C-class AMG W202 facelift (1997-2000) fuse and relay box Wiring diagram
This page shows the only wiring diagram for the component.fuse and relay box, which is found in the car Mercedes-Benz C-class AMG W202 facelift (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse and relay box (1 of 1)
AIR CONTROL MODULE (W/ AUXILIARY FAN)
AUXILIARY FAN
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAN L
ELECTRONIC IGNITION LOCK CONTROL MODULE
ENGINE CONTROL MODULE (ME-SFI)
ENGINE/ CLIMATE CONTROL ELECTRIC COOLING FAN
ENGINE/CLIMATE CONTROL ELECTRIC COOLING FAN CONTROL MODULE (W/ SUCTION FAN)
FUSE 38
FUSE AND RELAY BOX
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT SIGNAL PICKUP AND ACTIVATION MODULE
NCA WIRE
RED/WHT WIRE
RED/YEL WIRE
W/ SUCTION FAN W/ AUXILIARY FAN
WHT WIRE
Go to component -> Air conditioning circuits (2 of 2) -> FUSE AND RELAY BOX
