Mercedes-Benz C-class AMG W202 facelift (1997-2000) asr/sps control module/ esp/sps/bas control module Wiring diagram

A/C PUSHBUTTON CONTROL MODULE ASR/SPS CONTROL MODULE ASR/SPS CONTROL MODULE/ ESP/SPS/BAS CONTROL MODULE BAS CONTROL MODULE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE DATA LINK CONNECTOR (RIGHT REAR CORNER OF ENGINE COMPARTMENT) DRIVER'S SIDE FUSE, RELAY MODULE BOX ELECTRONIC IGNITION LOCK CONTROL MODULE ELECTRONIC SELECTOR LEVER MODULE CONTROL MODULE ENGINE CONTROL MODULE (ME-SFI) (RIGHT REAR OF ENGINE COMPT) ESP/SPS/BAS CONTROL MODULE FUSE 1 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEADLAMP RANGE ADJUSTMENT CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER NAVIGATION UNIT AND RADIO PASSENGER'S SIDE FUSE/ RELAY MODULE BOX RADIO RADIO, NAVIGATION OPERATING UNIT RED/GRN WIRE RED/WHT WIRE SRS CONTROL MODULE (FORWARD OF SHIFTER) TRANSMISSION CONTROL MODULE (REAR OF ENGINE COMPT) ULTRASONIC PTS CONTROL MODULE VIO WIRE WHT WIRE WHT/GRN (OR BLK/GRN) WIRE WHT/GRN WIRE XENON HEADLAMPS YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
