Mercedes-Benz C-class AMG W202 (1994-1997) stop tail backup marker turn fog Wiring diagram
This page shows the only wiring diagram for the component.stop tail backup marker turn fog, which is found in the car Mercedes-Benz C-class AMG W202 (1994-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop tail backup marker turn fog (1 of 1)
12.3
18/0
24/0 FUSE 24
24/3
28/2 22/0
4/3 FUSE BOX
6/2
BACKUP
BACKUP LIGHTS CIRCUIT
BLK WIRE
BLK/GRN WIRE
BLK/GRN/RED WIRE
BLK/GRN/WHT WIRE
BLK/RED WIRE
BLK/RED/BLU WIRE
BLK/RED/VIO WIRE
BLK/RED/WHT WIRE
BLK/WHT WIRE
BLK/WHT/BLU WIRE
BLU WIRE
BRN WIRE
BRN/GRY WIRE
CANADA
CANADA ONLY
CENTER HIGH MOUNTED STOP LIGHT
COMBINATION RELAY
COMBINATION SWITCH
DAYTIME RUNNING LIGHT CONTROL UNIT (BELOW LEFT SIDE OF I/P)
EXTERIOR LAMP FAILURE MONITORING MODULE (IN LEFT COMPONENT COMPT)
EXTERIOR LAMP SWITCH
EXTERIOR LIGHT FAILURE INDICATOR
FUSE 12
FUSE 28
FUSE 4
FUSE 6
FUSE BOX 18/0 FUSE 18
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLK/WHT WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/RED/WHT WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HAZARD FLASHER SWITCH
HEAD
HEAD LH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN OFF, ACCY
HOT IN RUN OR START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
LEFT TAILLAMP UNIT
LEFT TURN INDICATOR
LEFT TURN SIGNAL LIGHT
LH HEAD
MARKER
OFF
OFF PARK
OFF PARK RH
OFF RH PARK
RED WIRE
RED/WHT WIRE
RIGHT LICENSE PLATE LAMP LEFT LICENSE PLATE LAMP
RIGHT TAILLAMP UNIT
RIGHT TURN INDICATOR
RIGHT TURN SIGNAL LIGHT
STOP
STOP LAMP SWITCH
STOP TAIL BACKUP MARKER TURN FOG
TAIL
TURN
TURN SIGNAL SWITCH
USA
VIO WIRE
WARNING SYSTEM
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit -> STOP TAIL BACKUP MARKER TURN FOG
