Mercedes-Benz C-class AMG W202 (1994-1997) egr switch- over valve Wiring diagram

ADJUSTABLE CAMSHAFT TIMING SOLENOID AIR PUMP AIR PUMP RELAY MODULE AIR PUMP SWITCH- OVER VALVE BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE CKP SENSOR CMP SENSOR IAT SENSOR ECT SENSOR EGR SWITCH- OVER VALVE ENGINE CONTROL MODULE (IN RIGHT COMPONENT COMPARTMENT) GRN WIRE GRN/RED WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT FILM MAF SENSOR HOT IN RUN OR START IGNITION COIL 1 IGNITION COIL 2 INJ 1 INJ 4 INJ. #2 INJ. #3 ISC ACTUATOR KNOCK SENSOR (RIGHT SIDE OF ENGINE) MAXI- FUSE BOX FUSE 17 NCA WIRE PNK WIRE PNK/RED WIRE RED WIRE RED/BLU WIRE SOLID STATE SPARK PLUG 1 SPARK PLUG 4 SPARK PLUG 2 SPARK PLUG 3 TERMINAL BLOCK VIO WIRE WHT WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE
