Blind spot information system circuit for Mercedes-Benz B-class W246 facelift (2014-2018)
Blind spot information system circuit
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FUSE 90
HOT W/ CIRCUIT 15 RELAY ENERGIZED
LEFT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
LEFT FRONT DOOR CONTROL UNIT
LEFT OUTSIDE MIRROR
LEFT REAR BUMPER INTELLIGENT RADAR SENSOR
RIGHT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT OUTSIDE MIRROR
RIGHT REAR BUMPER INTELLIGENT RADAR SENSOR
SAM CONTROL UNIT
T A B(+)
T A W(+)
VEHICLE INTERIOR FUSE BOX
