Mercedes-Benz B-class W246 facelift (2014-2018) special-purpose vehicle multi-function control unit Wiring diagrams
This page contains all the electrical diagrams for the component. special-purpose vehicle multi-function control unit, in which he is found in the car Mercedes-Benz B-class W246 facelift (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram special-purpose vehicle multi-function control unit (1 of 3)
ATA (EDW)/ TOWING SENSOR/ INTERIOR MOTION SENSOR CONTROL UNIT
ATA (EDW)/TOWING SENSOR/INTERIOR MOTION SENSOR CONTROL UNIT
AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT
BRN WIRE
BRN/RED WIRE
CAMERA COVER CONTROL UNIT
CAN B H
CAN B L
CLA, GLA-CLASS B-CLASS ELECTRIC DRIVE
COMAND CONTROL UNIT
DRIVER SEAT CONTROL UNIT
FRONT PASSENGER SEAT CONTROL UNIT
INSTRUMENT CLUSTER
INTERIOR CAN (CAN B) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
KEYLESS-GO CONTROL UNIT
LEFT FRONT DOOR CONTROL UNIT
PANORAMIC SLIDING ROOF CONTROL MODULE
RIGHT FRONT DOOR CONTROL UNIT
SAM CONTROL UNIT
SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
STATIONARY HEATER UNIT
TRAILER RECOGNITION CONTROL UNIT
VIO WIRE
W/ PANAROMIC GLASS, TOP SLIDING SUNROOF
W/O PANAROMIC GLASS, TOP SLIDING SUNROOF
Go to component -> High/low bus circuit (3 of 4) -> SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
Wiring diagram special-purpose vehicle multi-function control unit (2 of 3)
BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
BRN/YEL WIRE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
LEFT, RIGHT ROOF LIGHT BAR ELECTRICAL CONNECTOR
MICROPHONE ELECTRICAL CONNECTOR
NCA WIRE
ORG/ WIRE
OUTSIDE SPEAKER ELECTRICAL CONNECTOR
PNK WIRE
RED/WHT WIRE
ROOF LIGHT BAR SIGNALING SYSTEM OPERATING UNIT ELECTRICAL CONNECTOR
SPECIAL SIGNAL SYSTEM OPERATING UNIT
SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
TACHOGRAPH ELECTRICAL CONNECTOR
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Panic alarm circuit (2 of 2) -> SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
Wiring diagram special-purpose vehicle multi-function control unit (3 of 3)
AMPLIFIER CONTROL UNIT
AUDIO COMAND CONTROL PANEL
AUDIO/ COMAND DISPLAY
AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT
BATTERY MANAGEMENT SYSTEM
BATTERY SENSOR
BLK WIRE
BLU/WHT WIRE
BRN WIRE
CONTROL UNIT)
DRIVER SEAT CONTROL UNIT
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT
ECO START/ STOP FUNCTION ADDITIONAL BATTERY RELAY
ELECTRIC PARKING BRAKE CONTROL UNIT
ELECTRICAL POWER STEERING CONTROL UNIT
FAN MOTOR
FRONT PASSENGER SEAT CONTROL UNIT
FUSE 1
FUSE 2
FUSE 21
FUSE 22
FUSE 27
FUSE 3
FUSE 32
FUSE 33
FUSE 34
FUSE 36
FUSE 37
FUSE 38
FUSE 39
FUSE 4
FUSE 5
FUSE 54
FUSE 55
FUSE 56
FUSE 57
FUSE 58
FUSE 59
FUSE 6
FUSE 61
FUSE 62
FUSE 63
FUSE 7
FUSE 73
FUSE 74
FUSE 75
FUSE 76
FUSE 77
FUSE 8
FUSE 98
GATEWAY FOR POWERTRAIN CONTROL UNIT
GRN/BRN WIRE
GRN/RED WIRE
KEYLESS-GO CONTROL UNIT
N/A
NCA WIRE
ON-BOARD ELECTRICAL SYSTEM BATTERY
OVERHEAD CONTROL PANEL CONTROL UNIT
PARK PAWL ACTUATOR MOTOR CIRCUIT 87 RELAY
PARK PAWL CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SAM CONTROL UNIT
SOUND SYSTEM
SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
STEERING COLUMN MODULE CONTROL UNIT
SUPPLEMENTAL RESTRAINT SYSTEM
TO DC/DC CONVERTER CONTROL UNIT (DIAGRAM 6 OF 6)
TO ENGINE COMPARTMENT FUSE, RELAY MODULE (DIAGRAM 2 OF 6)
TO ENGINE COMPARTMENT FUSE, RELAY MODULE (DIAGRAM 3 OF 6)
TO FUSE 109 (DIAGRAM 2 OF 6)
TO FUSE 47 (DIAGRAM 3 OF 6)
TO FUSE 60 (DIAGRAM 5 OF 6)
TRAILER RECOGNITION CONTROL UNIT
UHI
VEHICLE INTERIOR FUSE BOX
VIO/RED WIRE
W/ MEMORY
WHT/BRN WIRE
WHT/RED WIRE
Go to component -> Power distribution circuit (1 of 6) -> SPECIAL-PURPOSE VEHICLE MULTI-FUNCTION CONTROL UNIT
