Mercedes-Benz B-class W246 facelift (2014-2018) right side bag sensor Wiring diagram
This page shows the only wiring diagram for the component.right side bag sensor, which is found in the car Mercedes-Benz B-class W246 facelift (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right side bag sensor (1 of 1)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
DRIVER ETR (GUS) SQUIB
DRIVER SIDE BAG SQUIB
EMERGENCY CALL SYSTEM CONTROL UNIT
FRONT PASSENGER BELT FORCE LIMITER
FRONT PASSENGER ETR (GUS) SQUIB
FRONT PASSENGER SEAT OCCUPIED RECOGNITION
FRONT PASSENGER SIDE BAG SQUIB
FUSE 38
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOT W/
LEFT FRONTAL ACCELERATION SENSOR
LEFT SIDE BAG SENSOR
LEFT WINDOW BAG SQUIB
ORG/BLU WIRE
ORG/BRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONTAL ACCELERATION SENSOR
RIGHT SIDE BAG SENSOR
RIGHT WINDOW BAG SQUIB
SIG
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
VEHICLE INTERIOR FUSE BOX
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BRN WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
ZP (-)
ZP (-) C SIG
Go to component -> Supplemental restraint circuit (4 of 4) -> RIGHT SIDE BAG SENSOR
