Mercedes-Benz B-class W246 facelift (2014-2018) left front reversible emergency tensioning retractor Wiring diagrams

BRN WIRE CAN E H CAN E L CLA CLASS, GLA CLASS COMPUTER DATA LINES SYSTEM FUSE 44 FUSE 45 GRN WIRE GRN/WHT WIRE LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR RED/BLU WIRE RELAY ENERGIZED RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR VEHICLE INTERIOR FUSE BOX

ADAPTIVE DAMPING SYSTEM CONTROL UNIT BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN V H CAN V L CENTER REAR OF LUGGAGE COMPT) COLLISION PREVENTION ASSIST CONTROLLER UNIT DISTRONIC ELECTRIC CONTROLLER UNIT DRIVETRAIN CONTROL UNIT ELECTRIC PARKING BRAKE CONTROL UNIT ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT GATEWAY FOR POWER TRAIN CONTROL UNIT GRN WIRE GRN/WHT WIRE LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR LEFT REAR BUMPER INTELLIGENT RADAR SENSOR RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR RIGHT REAR BUMPER INTELLIGENT RADAR SENSOR STEERING COLUMN MODULE CONTROL UNIT SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT W/ DISTRONIC PLUS W/ DISTRONIC PLUS W/O ACTIVE PARK ASSIST W/ ACTIVE PARK ASSIST W/ PRE- SAFE W/O DISTRONIC PLUS

ASHTRAY ILLUMINATION BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BRN WIRE BRN/GRN WIRE CIGARETTE LIGHTER HEATING ELEMENT CIRCUIT 87 RELAY COMAND CONTROL UNIT COMAND FAN MOTOR DRIVE KIT CONTROL UNIT FOR IPHONE DRIVETRAIN CONTROL UNIT DUAL CLUTCH TRANSMISSION FULLY INTEGRATED CONTROL UNIT ELECTRIC REFRIGERANT COMPRESSOR ELECTRONIC STABILITY PROGRAM CONTROL UNIT ENGINE COMPARTMENT FUSE, RELAY MODULE FROM CIRCUIT 15 RELAY (DIAGRAM 2 OF 6) FROM FUSE 39 (DIAGRAM 1 OF 6) FROM FUSE 79 (DIAGRAM 2 OF 6) FROM VEHICLE INTERIOR FUSE BOX (DIAGRAM 1 OF 6) FRONT CIGAR LIGHTER W/ ASHTRAY ILLUMINATION FRONT PASSENGER SEAT CONTROL UNIT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT FUSE 100 FUSE 217 FUSE 218 FUSE 222 FUSE 234 FUSE 241 FUSE 40 FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 46 FUSE 47 FUSE 48 FUSE 49 FUSE 69 FUSE 70 FUSE 71 FUSE 72 FUSE 97 GRY/BLU WIRE HEATED REAR WINDOW RELAY HIGH-VOLTAGE PTC HEATER LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR LUGGAGE COMPARTMENT SOCKET MOBILE PHONE CONTACT PLATE N/A PANORAMIC SLIDING ROOF CONTROL MODULE REAR CENTER CONSOLE POWER OUTLET RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/PNK WIRE RED/WHT WIRE RESERVE FUSE 216 RESERVE FUSE 233 RESERVE FUSE 235 RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR SAM CONTROL UNIT TO CIRCUIT TO FUSE 99 (DIAGRAM 4 OF 6) TO HIGH-VOLTAGE POWER DISTRIBUTOR (DIAGRAM 6 OF 6) VEHICLE INTERIOR FUSE BOX (RIGHT FRONT FOOTWELL) VEHICLE INTERIOR POWER OUTLET W/ ASHTRAY PACKAGE/SMOKER PACKAGE W/O ASHTRAY PACKAGE/SMOKER PACKAGE W/ MEMORY W/ PRE- SAFE W/O MEMORY
