Mercedes-Benz B-class W246 facelift (2014-2018) driver trunk lid/liftgate control button Wiring diagram
This page shows the only wiring diagram for the component.driver trunk lid/liftgate control button, which is found in the car Mercedes-Benz B-class W246 facelift (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver trunk lid/liftgate control button (1 of 1)
ANTI-THEFT ALARM SYSTEM/EMERGENCY CALL SYSTEM BUTTON GROUP
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
DRIVER TRUNK LID/LIFTGATE CONTROL BUTTON
FOOTWELL ILLUMINATION SWITCH
FUSE 23
FUSE 24
FUSE 82
FUSE 88
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT ILLUMINATION, INSTRUMENT ILLUMINATION BRIGHTNESS CONTROL
LEFT FRONT DOOR CENTRAL LOCKING INTERIOR SWITCH
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT DOOR DOOR HANDLE ILLUMINATION
ORG/GRN WIRE
OVERHEAD CONTROL PANEL CONTROL UNIT
PASSENGER-SIDE POWER WINDOW SWITCH
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR CENTRAL LOCKING INTERIOR SWITCH
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT DOOR DOOR HANDLE ILLUMINATION
SIG
TRUNK LID RELEASE BUTTON
VEHICLE INTERIOR FUSE BOX
WHT WIRE
WHT/YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> DRIVER TRUNK LID/LIFTGATE CONTROL BUTTON
