Mercedes-Benz B-class W246 facelift (2014-2018) driver-side power window, outside mirror adjustment switch group Wiring diagram
This page shows the only wiring diagram for the component.driver-side power window, outside mirror adjustment switch group, which is found in the car Mercedes-Benz B-class W246 facelift (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver-side power window, outside mirror adjustment switch group (1 of 1)
AUTOMATIC DIMMING MIRROR
BLK WIRE
BRN WIRE
BRN/PNK WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP
FUSE 24
GRN WIRE
HORIZONTAL INCLINATION ADJUSTMENT ACTUATOR MOTOR
HORIZONTAL INCLINATION ADJUSTMENT POTENTIOMETER
HOT AT ALL TIMES
LEFT OUTSIDE MIRROR ADJUSTMENT SWITCH
MIRROR HEATER
MOT-
OUTSIDE MIRROR ADJUSTMENT SWITCH
OUTSIDE MIRROR FOLD-IN/ FOLD-OUT SWITCH
OUTSIDE MIRROR FOLD-IN/FOLD-OUT ELECTRIC MOTOR
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT BLIND SPOT ASSIST READINESS, WARNING INDICATOR
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP
RIGHT OUTSIDE MIRROR
RIGHT OUTSIDE MIRROR ADJUSTMENT SWITCH
RIGHT OUTSIDE MIRROR AMBIENT LAMP
RIGHT OUTSIDE MIRROR TURN SIGNAL LAMP
SIG
TA B (+)
TA W (+)
VEHICLE INTERIOR FUSE BOX
VERTICAL INCLINATION ADJUSTMENT ACTUATOR MOTOR
VERTICAL INCLINATION ADJUSTMENT POTENTIOMETER
Go to component -> Memory mirrors circuit (1 of 2) -> DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP
