Mercedes-Benz B-class W246 facelift (2014-2018) dedicated short-range communications control unit Wiring diagrams
This page contains all the electrical diagrams for the component. dedicated short-range communications control unit, in which he is found in the car Mercedes-Benz B-class W246 facelift (2014-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dedicated short-range communications control unit (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
DEDICATED SHORT-RANGE COMMUNICATIONS CONTROL UNIT
EMERGENCY CALL SYSTEM CONTROL UNIT
ETC/DSRC ANTENNA
GRN WIRE
HSD
MF (-)
MULTIMEDIA CONNECTION UNIT
NCA WIRE
ORG/ WIRE
RED/BLU WIRE
SHIELD
TEL ST
TELEMATICS SERVICES COMMUNICATION MODULE
USB D-
USB GND
USB SPLITTER
YEL/BLU WIRE
Go to component -> Comand actuation circuit (3 of 4) -> DEDICATED SHORT-RANGE COMMUNICATIONS CONTROL UNIT
