Mazda Tribute II (2007-2011) Forced entry circuit, hybrid

ALL LOCK RELAY ALL UNLOCK RELAY BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE DOOR AJAR DRIVER UNLOCK RELAY DRIVER'S SIDE FRONT DOOR LOCK UNIT DOOR AJAR (IN DRIVER'S DOOR) FET FUSE 17 FUSE 24 FUSE 41 GRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE HORN RELAY HORNS SYSTEM HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED LEFT REAR DOOR LOCK ACTUATOR LIFTGLASS RELEASE RELAY MICROCOMPUTER SMART JUNCTION BOX (BEHIND CENTER OF DASH) VIO/GRY WIRE WHT WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE

BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE DOOR DOOR AJAR DRIVER SIDE DOOR LOCK SWITCH FRONT PASSENGER'S SIDE DOOR LOCK UNIT (IN FRONT PASSENGER'S GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE LEFT LICENSE PLATE LAMP LIFTGATE AJAR SWITCH LIFTGATE GLASS AJAR SWITCH LIFTGATE GLASS RELEASE SWITCH LIFTGATE LOCK ACTUATOR (IN TAILGATE ASSEMBLY) LIFTGATE RELEASE SWITCH LOCK LT GRN WIRE PASSENGER SIDE DOOR LOCK SWITCH RIGHT LICENSE PLATE LAMP RIGHT REAR DOOR LOCK ACTUATOR UNLOCK UNLOCK LOCK VIO/GRY WIRE WHT WIRE YEL WIRE YEL/ORG WIRE YEL/VIO WIRE
