Horn circuit for Mazda Tribute I facelift (2004-2007)
Horn circuit
0922-203 AIR BAG SLIDING CONTACT (BEHIND LEFT SIDE OF DASH)
BATTERY JUNCTION BOX (ON LEFT SIDE OF ENGINE COMPT) FUSE 8
BLK WIRE
DK BLU WIRE
FUSE 20
HORN SWITCH
HOT AT ALL TIMES
LEFT HORN (AT LEFT FRONT CORNER OF ENGINE COMPT)
LT GRN WIRE
MICRO COMPUTER
NCA WIRE
RIGHT HORN (AT RIGHT FRONT CORNER OF ENGINE COMPT)
SMART JUNCTION BOX (REAR CENTER HORN RELAY OF ENGINE COMPT)
YEL WIRE
