Mazda Tribute I facelift (2004-2007) right left select switch wiring diagram
This page shows the only wiring diagram for the component.right left select switch, which is found in the car Mazda Tribute I facelift (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right left select switch wiring diagram (1 of 1)
BLK WIRE
DEFOGGER SYSTEM
DK BLU WIRE
DK GRN WIRE
DOWN
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
EXTERIOR REAR VIEW MIRROR SWITCH
FUSE 7
GRN WIRE
HOT AT ALL TIMES
LEFT
LEFT RIGHT
LEFT/RIGHT
LT GRN WIRE
ORG/ WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
RED WIRE
RIGHT DOWN
RIGHT LEFT
RIGHT LEFT SELECT SWITCH
SMART JUNCTION BOX (REAR CENTER OF ENGINE COMPT)
UP/DOWN
VIO WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> RIGHT LEFT SELECT SWITCH
