Instrument illumination circuit for Mazda Tribute I (2000-2004)

BLK WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) FOG LAMP SWITCH FOUR WHEEL DRIVE SWITCH FUNCTION SELECTOR SWITCH ASSEMBLY FUSE 15 FUSE 18 GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER CENTER OF DASH) GRY WIRE HAZARD FLASHER SWITCH HEAD HOT AT ALL TIMES ILLUMINATION DIMMER INSTRUMENT CLUSTER (METER) LIGHT SWITCH LT BLU WIRE LT GRN WIRE MICRO- PROCESSOR OFF ORG/ WIRE PARK PARK LAMP RELAY REAR WINDOW DEFROST SWITCH RED WIRE TAN WIRE VIO WIRE WHT WIRE
