2.0l, manual a/c circuit for Mazda Tribute I (2000-2004)

A/C CLUTCH RELAY A/C CLUTCH SOLENOID A/C COMPRESSOR CLUTCH DIODE BATTERY JUNCTION BOX (ON LEFT FRONT CORNER OF ENGINE COMPARTMENT) BLK WIRE BLK/LT BLU WIRE BLK/LT GRN WIRE BLK/YEL WIRE BLOWER MOTOR RELAY (BEHIND LOWER LEFT CENTER OF DASH) BLU WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) CYLINDER HEAD TEMPERATURE (CHT) SENSOR (ON RIGHT FRONT OF CYLINDER HEAD) DK BLU WIRE DK BLU/GRY WIRE DK GRN/ORG WIRE FRONT BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) FUSE 17 FUSE 2 FUSE 23 FUSE 25 FUSE 26 FUSE 9 GRY WIRE GRY/RED WIRE GRY/WHT WIRE HIGH SPEED FAN CONTROL RELAY 1 HOT AT ALL TIMES HOT IN RUN OR START LOW SPEED FAN CONTROL RELAY LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/RED WIRE MEDIUM SPEED FAN CONTROL RELAY ORG/ WIRE ORG/BLK WIRE PCM POWER DIODE PNK WIRE PNK/BLK WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (PCM) (IN RECESS ON UPPER CENTER OF FIREWALL) RED WIRE RED/ORG WIRE TAN/YEL WIRE VIO WIRE WHT WIRE WHT/VIO WIRE

BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE BLK/YEL WIRE BRN/YEL WIRE DEFROST DK GRN/ORG WIRE DK GRN/YEL WIRE DUAL PRESSURE SWITCH (ON LOWER RIGHT FRONT OF ENGINE COMPARTMENT) FLOOR/DEFROST FLOOR/DEFROST FLOOR OFF FRONT BLOWER MOTOR RESISTOR ASSEMBLY (BEHIND RIGHT SIDE OF DASH) FUNCTION SELECTOR SWITCH ASSEMBLY HIGH MED 2 BLOWER MOTOR SWITCH ILLUMINATION LT BLU/RED WIRE LT GRN/WHT WIRE MAX A/C A/C MAX A/C A/C PANEL PANEL/ FLOOR FLOOR OFF MED 1 LOW MODE SWITCH ORG/ WIRE ORG/BLK WIRE PANEL PANEL/ FLOOR RED/YEL WIRE VIO WIRE YEL/RED WIRE
