Charging circuit for Mazda RX-8 I facelift (2008-2012)

BATTERY BLK WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BRN WIRE CHARGE INDICATOR COMPUTER DATA LINES SYSTEM FUSE BLOCK (DASH) (BEHIND LEFT KICK PANEL) GENERATOR GRN WIRE IG KEY FUSE IGNITION SWITCH INSTRUMENT CLUSTER J/C G-10 LOCK MAIN FUSE METER FUSE MICROCOMPUTER NCA WIRE PCM (AT RIGHT FRONT OF ENGINE COMPT) POWER DISTRIBUTION SYSTEM RED WIRE RELAY, MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL) STARTER WHT WIRE YEL WIRE
