Mazda RX-8 I facelift (2008-2012) clock spring (under steering column) wiring diagram
This page shows the only wiring diagram for the component.clock spring (under steering column), which is found in the car Mazda RX-8 I facelift (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
clock spring (under steering column) wiring diagram (1 of 1)
ANTI-LOCK BRAKES SYSTEM
AUDIO CONTROL SWITCH
AUDIO UNIT
AUXILIARY JACK
BLK WIRE
BLK/BLU WIRE
BLU/RED WIRE
CLOCK SPRING (UNDER STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
FUSE BLOCK (DASH) (BEHIND LEFT
FUSE KICK PANEL)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/WHT WIRE
HANDS FREE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
LEFT FRONT RIGHT FRONT DOOR SPEAKER TWEETER
LEFT FRONT TWEETER
LEFT REAR DOOR SPEAKER
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
MODE
MUTE SW/
NCA WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
ROOM FUSE
SEEK
VIO WIRE
VOICE REC
VOL (-)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL/RED WIRE
Go to component -> Radio circuit, without bose -> CLOCK SPRING (UNDER STEERING COLUMN)
