Tire pressure monitoring circuit for Mazda RX-8 I (2003-2008)

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE COMPUTER COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM FUSE BLOCK (DASH) (BEHIND LEFT KICK PANEL) ROOM FUSE GRN/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER J/C G-10 METER FUSE MICROCOMPUTER RED WIRE TPMS CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) TPMS IND YEL WIRE
