Power door locks circuit, with advanced keyless entry & start system for Mazda RX-8 I (2003-2008)

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE COIL (BEHIND LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM D LOCK FUSE DRIVER SIDE REQUEST SWITCH ENGINE FUSE FRONT INTERIOR KEYLESS ANTENNA (BEHIND RIGHT SIDE OF DASH) FUSE FUSE BLOCK (BEHIND LEFT KICK PANEL) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START HOT IN START OR RUN HOT W/ ACC RELAY ENERGIZED J/C G-16 KEYLESS BEEPER KEYLESS CONTROL MODULE (BEHIND RIGHT END OF DASH) KEYLESS RECEIVER (BEHIND CENTER OF DASH) LEFT FRONT EXTERIOR KEYLESS ANTENNA (IN DRIVER'S DOOR) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE METER FUSE MIDDLE INTERIOR KEYLESS ANTENNA (UNDER FRONT OF CENTER FLOOR CONSOLE) ORG/ WIRE PASSENGER SIDE REQUEST SWITCH PNK WIRE PNK/BLK WIRE PNK/BLU WIRE REAR EXTERIOR KEYLESS ANTENNA (CENTER REAR OF LUGGAGE COMPT) REAR INTERIOR KEYLESS ANTENNA (UNDER REAR OF CENTER FLOOR CONSOLE) RED WIRE RED/WHT WIRE RELAY, MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL) RIGHT FRONT EXTERIOR KEYLESS ANTENNA (IN FRONT PASSENGER'S DOOR) ROOM FUSE STEERING LOCK UNIT TRUNK LID KEYLESS ANTENNA (REAR OF TRUNK LID) TRUNK REQUEST SWITCH TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE DOOR IND DOOR LOCK CONTROL MODULE GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE HEADLIGHTS SYSTEM (W/ DRL) HOOD LATCH SWITCH (AT CENTER FRONT OF ENGINE COMPT) HORNS SYSTEM INSTRUMENT CLUSTER BUZZER J/C G-16 LEFT DOOR LOCK SWITCH LEFT FRONT BUCKLE SWITCH (UNDER LEFT FRONT SEAT) LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT LOCK RELEASE SOLENOID LEFT REAR DOOR LOWER LATCH SWITCH LT GRN WIRE MICROCOMPUTER ORG/ WIRE PNK WIRE PNK/BLK WIRE POWER WINDOWS SYSTEM (W/O DRL) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT BUCKLE SWITCH (UNDER RIGHT FRONT SEAT) RIGHT LOCK RELEASE SOLENOID RIGHT REAR DOOR LOWER LATCH SWITCH (AT RIGHT "B" PILLAR) SECURITY IND TRUNK, TAILGATE, FUEL DOORS SYSTEM UN- LOCK LOCK VIO WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
