Mazda RX-8 I (2003-2008) driver side request switch Wiring diagrams
This page contains all the electrical diagrams for the component. driver side request switch, in which he is found in the car Mazda RX-8 I (2003-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver side request switch wiring diagram (1 of 2)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/YEL WIRE
COIL (BEHIND LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
D LOCK FUSE
DRIVER SIDE REQUEST SWITCH
ENGINE FUSE
FRONT INTERIOR KEYLESS ANTENNA (BEHIND RIGHT SIDE OF DASH)
FUSE
FUSE BLOCK (BEHIND LEFT KICK PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN START OR RUN
HOT W/ ACC RELAY ENERGIZED
J/C G-16
KEYLESS BEEPER
KEYLESS CONTROL MODULE (BEHIND RIGHT END OF DASH)
KEYLESS RECEIVER (BEHIND CENTER OF DASH)
LEFT FRONT EXTERIOR KEYLESS ANTENNA (IN DRIVER'S DOOR)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
METER FUSE
MIDDLE INTERIOR KEYLESS ANTENNA (UNDER FRONT OF CENTER FLOOR CONSOLE)
ORG/ WIRE
PASSENGER SIDE REQUEST SWITCH
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
REAR EXTERIOR KEYLESS ANTENNA (CENTER REAR OF LUGGAGE COMPT)
REAR INTERIOR KEYLESS ANTENNA (UNDER REAR OF CENTER FLOOR CONSOLE)
RED WIRE
RED/WHT WIRE
RELAY, MAIN FUSE BLOCK (ON LEFT FRONT INNER FENDER PANEL)
RIGHT FRONT EXTERIOR KEYLESS ANTENNA (IN FRONT PASSENGER'S DOOR)
ROOM FUSE
STEERING LOCK UNIT
TRUNK LID KEYLESS ANTENNA (REAR OF TRUNK LID)
TRUNK REQUEST SWITCH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO/GRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit, with advanced keyless entry & start system (1 of 2) -> DRIVER SIDE REQUEST SWITCH
