Instrument illumination circuit for Mazda MX-6 I (1992-1997)

ASHTRAY ILLUMINATION AUDIO ILLUMINATION BLK WIRE BLU WIRE BRN WIRE CENTRAL PROCESSING UNIT (CPU) CIGARETTE LIGHTER ILLUMINATION CRUISE CONTROL MAIN SWITCH ILLUMINATION EXTERIOR LIGHTS SYSTEM (PARK LIGHT SWITCH) EXTERIOR LIGHTS SYSTEM (PARK LIGHTS) FRONT FOG LIGHT SWITCH ILLUMINATION GLOVE COMPARTMENT LIGHT (1995 ONLY) GLOVE COMPARTMENT LIGHT SWITCH (1995 ONLY) GRN WIRE GRN/YEL WIRE GRY WIRE HAZARD SWITCH ILLUMINATION HEATER CONTROL ILLUMINATION HOT AT ALL TIMES TAIL FUSE INSTRUMENT CLUSTER ILLUMINATION (4 USED) JC-02 JOINT BOX (BEHIND LEFT SIDE OF DASH) JOINT CONNECTOR (LEFT SIDE OF I/P) MAIN FUSE BLOCK (LEFT FRONT SIDE OF ENGINE COMPARTMENT) ORG/ WIRE OSCILLATOR PANEL LIGHT CONTROL SWITCH REAR WINDOW DEFROSTER SWITCH ILLUMINATION RED/BLK WIRE RED/GRN WIRE SELECTOR ILLUMINATION (A/T) TNS RELAY (LEFT REAR OF ENGINE COMPARTMENT) WHT WIRE
