Mazda MX-6 I (1992-1997) c-01 Wiring diagrams

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/PNK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLK WIRE C-01 EGR SOLENOID VALVE-VACUUM (RIGHT REAR OF ENGINE COMPARTMENT) EGR SOLENOID VALVE-VENT (RIGHT REAR OF ENGINE COMPARTMENT) EGR VALVE POSITION SENSOR (CENTER REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (LEFT FRONT OF ENGINE COMPT) FUEL PUMP FUEL PUMP RELAY FUEL TANK UNIT GRN/BLU WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HEATED OXYGEN SENSOR (LOWER RIGHT SIDE OF ENGINE, ON EXHAUST PIPE) HOT IN ON HOT IN START OR ON IDLE AIR CONTROL VALVE (LEFT REAR OF ENGINE COMPARTMENT) INSTRUMENT CLUSTER INTAKE AIR TEMPERATURE SENSOR (LEFT FRONT OF ENGINE COMPT) JB-03 JC-02 (LEFT SIDE OF I/P) JOINT BOX (LEFT KICK PANEL) LEFT FRONT FENDER) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) MALFUNCTION INDICATOR (CHECK ENGINE) MASS AIR FLOW SENSOR (LEFT REAR OF ENGINE COMPT) METER FUSE 8 NCA WIRE O/D OFF SWITCH (CENTER CONSOLE) ORG/GRN WIRE PNK/BLK WIRE PNK/BLU WIRE POWER STEERING PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPARTMENT) PRC SOLENOID VALVE (RIGHT REAR OF ENGINE COMPARTMENT) PURGE SOLENOID VALVE (RIGHT REAR OF ENGINE COMPARTMENT) RED WIRE RED/BLK WIRE RED/GRN WIRE SPEEDOMETER THROTTLE POSITION SENSOR (TOP REAR OF ENGINE) VIO/RED WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE WIPER FUSE 13 YEL WIRE YEL/GRN WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE C-01 CLUTCH PEDAL SWITCH (ON CLUTCH PEDAL SUPPORT) CRUISE CONTROL UNIT (PIN J) EGR SOLENOID VALVE-VACUUM (RIGHT REAR OF ENGINE COMPARTMENT) EGR SOLENOID VALVE-VENT (RIGHT REAR OF ENGINE COMPARTMENT) EGR VALVE POSITION SENSOR (CENTER REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (LEFT SIDE OF ENGINE) FUEL PUMP FUEL PUMP RELAY FUEL TANK UNIT GRN/BLU WIRE GRN/YEL WIRE GRY/RED WIRE HEATED OXYGEN SENSOR (LOWER RIGHT SIDE OF ENGINE, ON EXHAUST PIPE) HOT IN RUN HOT IN START OR ON IDLE AIR CONTROL SOLENOID VALVE (LEFT REAR OF ENGINE COMPARTMENT) INSTRUMENT CLUSTER INTAKE AIR TEMPERATURE SENSOR (LEFT SIDE OF ENGINE) J/C X-22 (RIGHT SIDE OF CENTER CONSOLE) JB-03 JC-01 (BEHIND LEFT HEADLIGHT) JOINT BOX (LEFT KICK PANEL) LT GRN WIRE MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) MALFUNCTION INDICATOR (CHECK ENGINE) MASS AIR FLOW SENSOR (LEFT REAR OF ENGINE COMPT) METER FUSE 8 NCA WIRE NEUTRAL SWITCH (ON SIDE OF TRANSMISSION) PNK/GRN WIRE PRC SOLENOID VALVE (RIGHT REAR OF ENGINE COMPARTMENT) PURGE SOLENOID VALVE (RIGHT REAR OF ENGINE COMPARTMENT) RED WIRE RED/BLK WIRE STARTER INTERRUPT RELAY COIL THROTTLE POSITION SENSOR CENTER REAR OF ENGINE) VIO/RED WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE WIPER FUSE 13 YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/BLU WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE C-01 CLUTCH PEDAL POSITION SWITCH (M/T) (ON CLUTCH PEDAL SUPPORT) DATA LINK CONNECTOR (LEFT SIDE OF ENGINE) EGR SOLENOID VALVE-VACUUM (RIGHT REAR OF ENGINE COMPT) EGR SOLENOID VALVE-VENT (RIGHT REAR OF ENGINE COMPT) EGR VALVE POSITION SENSOR (CENTER REAR OF ENGINE) ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE) FUEL PUMP FUEL PUMP RELAY FUEL TANK UNIT GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT IN START OR ON IDLE AIR CONTROL VALVE (LEFT SIDE OF ENGINE) INSTRUMENT CLUSTER MALFUNCTION INDICATOR (CHECK ENGINE) J/C X-22 (RIGHT SIDE OF CENTER CONSOLE) JB-03 JC-01 (BEHIND LEFT HEADLIGHT) JOINT BOX (LEFT KICK PANEL) KNOCK SENSOR (LEFT REAR OF ENGINE) LEFT HEATED OXYGEN SENSOR (LOWER LEFT SIDE OF ENGINE, ON EXHAUST PIPE) LT GRN WIRE M/T A/T MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) METER FUSE 8 NEUTRAL POSITION SWITCH (M/T) (LEFT SIDE OF ENGINE) PNK/BLK WIRE PNK/GRN WIRE PRC SOLENOID VALVE (LEFT SIDE OF ENGINE) PURGE SOLENOID VALVE (RIGHT REAR OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT HEATED OXYGEN SENSOR (LOWER RIGHT SIDE OF ENGINE, ON EXHAUST PIPE) THROTTLE POSITION SENSOR (FRONT TOP LEFT OF ENGINE) TRANSMISSION CONTROL MODULE (A/T) (BELOW CENTER OF I/P) VOLUME AIR FLOW SENSOR (LEFT SIDE OF ENGINE) VRIS SOLENOID VALVE NO. 1 (RIGHT REAR OF ENGINE COMPT) VRIS SOLENOID VALVE NO. 2 (RIGHT REAR OF ENGINE COMPT) WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE
