Car Wiring Diagrams for Wiper/washer circuit for Mazda MX-5 ND (2015-2024)

AT FUSE AUTO LIGHT SENSOR/RAIN SENSOR AUTO STOP SWITCH BCM BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE C-04 C-17 C-17 C-19 CIRCUIT BREAKER COMPUTER DATA LINES SYSTEM ELECTRICAL SUPPLY UNIT (ESU) F WASHER FUSE FUSE BLOCK GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INT AUTO LO OFF MIST HI INTERIOR FUSE METER 1 FUSE MICROCOMPUTER NCA WIRE RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED START STOP UNIT (LEFT SIDE OF DASH) VIO WIRE WARNING/ INDICATOR LIGHTS WASHER FLUID LEVEL SENSOR WASHER MOTOR WASHER SWITCH WHT WIRE WIPER FUSE WIPER HI RELAY WIPER INT RELAY WIPER MOTOR WIPER/ WASHER SWITCH
