Car Wiring Diagrams for Starting circuit for Mazda MX-5 ND (2015-2024)

0119-103 BATTERY BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE C-01 C-04 C-07 C-14 C-18 C-19 C-32 CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM GRN/BLU WIRE GRY WIRE GRY/BLU WIRE LT GRN WIRE M/T MAIN FUSE PCM RELAY & FUSE BLOCK START STOP UNIT STARTER STARTER INTERLOCK SWITCH STARTER RELAY STR/ALT FUSE TCM TRANSMISSION RANGE SWITCH WHT WIRE WHT/BLK WIRE
