Mazda MX-5 ND (2015-2024) right front roof link motor Wiring diagram
This page shows the only wiring diagram for the component.right front roof link motor, which is found in the car Mazda MX-5 ND (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front roof link motor (1 of 1)
0916-106
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
C-48
DOOR LOCKS SYSTEM
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
INTERIOR FUSE
J/C C-45
J/C C-46
LT BLU WIRE
LT GRN/VIO WIRE
NCA WIRE
PNK WIRE
R DECK L FUSE
R DECK R FUSE
RED WIRE
RED/YEL WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
RETRACTABLE HARDTOP CONTROL MODULE
RHT L FUSE
RHT R FUSE
RIGHT FRONT ROOF LINK MOTOR
RIGHT REAR ROOF LINK MOTOR
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power top/sunroof circuit (1 of 2) -> RIGHT FRONT ROOF LINK MOTOR
