Mazda MX-5 ND (2015-2024) left rear roof link motor Wiring diagram
This page shows the only wiring diagram for the component.left rear roof link motor, which is found in the car Mazda MX-5 ND (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear roof link motor (1 of 1)
0916-105
BLU WIRE
BRN WIRE
C-47
C-50
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
GRN WIRE
GRY WIRE
LEFT FRONT ROOF LINK LIMIT SWITCH
LEFT FRONT ROOF LINK MOTOR
LEFT REAR ROOF LINK LIMIT SWITCH
LEFT REAR ROOF LINK MOTOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
RED WIRE
RED/YEL WIRE
RETRACTABLE HARDTOP CONTROL MODULE
RIGHT FRONT ROOF LINK LIMIT SWITCH
RIGHT REAR ROOF LINK LIMIT SWITCH
TAN WIRE
TOP LOCK MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> LEFT REAR ROOF LINK MOTOR
