Mazda MX-5 NC facelift (2008-2015) Manual a/c circuit

0740-108 AIR INTAKE ACTUATOR (TOP LEFT SIDE OF AIR INTAKE BOX) AIR MIX ACTUATOR (TOP CENTER OF AIR INTAKE BOX) AX C-03 AQ BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLOWER MOTOR (BOTTOM RIGHT OF A/C UNIT) BLOWER RELAY (HEATER) (IN RELAY, MAIN FUSE BLOCK) BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE C-03 C-04 CLIMATE CONTROL UNIT DEFOGGER SYSTEM EVAPORATOR TEMPERATURE SENSOR (RIGHT SIDE OF A/C UNIT) FIELD EFFECT TRANSISTOR (POWER MOS FET) (ON A/C UNIT BLOWER HOUSING) GRN WIRE GRY/RED WIRE HEATER FUSE HOT AT ALL TIMES HOT IN RUN FUSE BLOCK A/C FUSE (BEHIND LEFT END OF DASH) INSTRUMENT CLUSTER J/C 8 MICROCOMPUTER NCA WIRE POWER METAL OXIDE SEMICONDUCTOR RED/BLU WIRE RED/WHT WIRE RELAY, MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) ROOM FUSE SOUND SYSTEMS VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/GRN WIRE

A/C RELAY BLK WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE C-02 C-03 COOLING FAN MOTOR (BEHIND RADIATOR) COOLING FAN RELAY 1 COOLING FAN RELAY 2 COOLING FAN RELAY 3 ENGINE COOLANT TEMPERATURE SENSOR (TOP REAR OF ENGINE) FAN FUSE GRN WIRE GRN/RED WIRE HOT AT ALL TIMES J/C 2 LT GRN WIRE LT GRN/RED WIRE MAG FUSE MAGNETIC CLUTCH (LEFT FRONT OF ENGINE, ON A/C COMPRESSOR) PCM (LEFT FRONT CORNER OF ENGINE COMPT) REAR WINDOW DEFROSTER RELAY (DEFOG) RED WIRE RED/BLU WIRE RED/WHT WIRE REFRIGERANT PRESSURE SWITCH (RIGHT FRONT OF ENGINE COMPT) RELAY, MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
