Mazda MX-5 NC (2005-2008) ab ac ad ae af ag ah ai aj ak al am an ao ap aq ar as at Wiring diagram

AB AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR AS AT ABS FUSE BLK WIRE BLK/BLU WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE IND BRAKE SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) COMPUTER COMPUTER DATA LINES SYSTEM DSC HU/CM (RIGHT FRONT OF ENGINE COMPT) DSC IND DSC OFF DSC OFF SWITCH RIGHT FRONT ABS WHEEL SPEED SENSOR ENGINE FUSE FUSE BLOCK (BEHIND LEFT END OF DASH) GRN/BLK WIRE GRN/WHT WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ IGNITION RELAY ENGERIZED IND INSTRUMENT CLUSTER J/C LEFT FRONT ABS WHEEL- SPEED SENSOR (AT LEFT FRONT WHEEL) LEFT REAR ABS WHEEL SPEED SENSOR METER FUSE MICRO - NCA WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RELAY, MAIN FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) ROOM FUSE RIGHT REAR ABS WHEEL- SPEED SENSOR (AT RIGHT REAR WHEEL) STEERING ANGLE SENSOR (IN STEERING COLUMN) STOP FUSE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
