Mazda MX-5 NB facelift (2001-2005) Manual a/c circuit

A/C FUSE A/C RELAY (AT LEFT FRONT OF ENGINE COMPARTMENT) A/C SWITCH AD FAN FUSE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER FUSE BLOWER MOTOR BLOWER RELAY (BEHIND LEFT SIDE OF DASH) BLOWER UNIT BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE CONDENSER FAN CONDENSER FAN RELAY (AT LEFT FRONT OF ENGINE COMPARTMENT) COOLING FAN MOTOR COOLING FAN RELAY (AT RIGHT REAR OF ENGINE COMPARTMENT) DEFROSTER SWITCH ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (ON TOP REAR OF ENGINE) ENGINE FUSE EVAPORATOR TEMPERATURE SENSOR FAN FUSE FAN SWITCH FUSE BLOCK (BEHIND LEFT SIDE OF DASH) G-10 G-11 GRY WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START JC-02 JC-03 LT GRN WIRE LT GRN/BLK WIRE MAGNETIC CLUTCH MAIN FUSE BLOCK (AT RIGHT REAR OF ENGINE COMPARTMENT) NCA WIRE PCM (BEHIND LEFT SIDE OF DASH) PNK PNK WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE REFRIGERANT PRESSURE SWITCH (AT RIGHT FRONT OF ENGINE COMPT) RESISTOR RUN WIRE THERMAL PROTECTOR (AT LEFT FRONT OF ENGINE COMPARTMENT) THERMOSWITCH (BEHIND RIGHT CENTER OF DASH) WHT WIRE X-01 X-03 YEL WIRE
