Mazda MX-5 NA (1989-1998) Charging circuit

1995-96 1997 ALTERNATOR BATTERY BLK WIRE BLK/YEL WIRE CHARGE IND FUSE BLOCK (LEFT KICK PANEL) HOT IN ON OR START INSTRUMENT CLUSTER MAIN FUSE BLOCK (RIGHT REAR CORNER OF ENGINE COMPARTMENT) MAIN FUSE FUEL INJ FUSE MAIN RELAY METER FUSE NCA WIRE STARTER WHT WIRE WHT/BLK WIRE WHT/GRN WIRE
